Product Description
Shakespeare 390 23′ Single Side Band Antenna NOT UPS SHIPPABLE
THIS PRODUCT MUST SHIP TRUCK FREIGHT AND DOES NOT QUALIFY FOR ANY SHIPPING PROMOTIONS
Shakespeare Style 390 SSB
23′ LENGTH
WHIP ANTENNA WITH CONDUCTORS RUNNING FULL-LENGTH (NO LOADING COIL)
This award-winning performer is often referred to as "the standard of the industry" by virtue of its capabilities and popularity. Reinforced insulating qualities allow input power up to 1 kw. Conductors are permanently sealed in Shakespeare white fiberglass.
- Chrome-plated brass ferrules, bottom ferrule has 1"-14 thread
- Side feed termination band
- Suggested mount: Shakespeare Style 409-R or 410-R Mounting Kit for deck or side mounting
- Two sections: Base 162"; Tip 112"
- Shakespeare Limited Warranty: 2 years
Technical Specifications:
| Frequency: | 2-30 MHz HF band with tuner |
| Bandwidth: | Resonant frequency 10.8 MHz |
| SWR: | N/A |
| Impedance: | (Ohms): N/A |
| Gain: | N/A |
| Max Input (Watts): | 1000 |
| DC Ground: | N/A |
| Termination: | Side Termination |
| Height (feet): | 23 |
| Polarization: | Vertical |
| Radiation pattern: | Omni-directional |
WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Product Information
| Weight: | 20 lbs |
| Dimensions: | 168 × 3 × 3 in |
| Truck Freight Required: | Yes |
| Ships Direct from Vendor: | Yes |
California Prop 65 Warning
WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Product Manuals & Guides
Product Specifications
| Manufacturer Part Number | 390 |
| Manufacturer Name | Shakespeare |
| Drop Ships Direct from vendor | yes |
| Hazardous materials | no |
| Truck Freight | yes |
| Exportable | yes |
| First Class Mail | no |
| Oversized | no |
| Remanufactured | no |
| Closeout | no |
| Harmonization Code | 8529.10.40.40 |
| Country Of Origin | CN, CHINA |
| Prop 65 | no, yes |
| Returnable | yes |
